PCB Manufacturing Machine Pictures List

Here are some equipments to make flexible PCB (flex circuit board), but not limited to follows. We keep used state-of-art machine to make high quality flexible PCB ( flexible printed circuit board).

PCB Manufacturing Machine List

Equipments		Function
Drill	CNC Dril l	Process for Making Through-holes for Double-sided or Multi-layer FPC
	Laser Drill
Copper Plating Machine		Plating for electrically connecting each layer by Through-holes
Exposure Machine	For Single-side	Photo Imaging for making circuit on the Photo Imagable Film (Roll to Roll Process)
	For Double-side
Etching Machine		Etching process for making circuit(Roll to Roll Process)
Hot Press		The Process for Coverlay Laminating or Outlayer Stacking up for Multi-layer Flexible Circuits ( flex printed circuit)
Printer		Silk Screen Printing for Solder Resist Ink or Marking
Gold Plating Machine		Surface Treatment for better solderbility or Anti-discolloring
Bare Board Tester		Test Equipment for checking electrical performance of Flexible Circuits

CNC Drill

Copper Plating Machine(Vertical Type)

Exposure Machine For Single-side

Exposure Machine For Double-side

Etching Machine

Hot-Press

Solder Resist Printer

Gold Plating Machine

Solder Resist Printer
